AZEV140 - 40 AMP POWER RELAY
Features:
- Dielectric strength 4000 Vrms
- Contact gap greater than 2.25mm
- Class F insulation system
- IEC 62752 & IEC 62955 compliant
- UL, CUR, TUV Certified
Engineering Resources
| Contact ratings | Coil Voltage | Contact forms | Coil Power at pickup voltage | ||
|---|---|---|---|---|---|
| 40 A at 440 VAC, Res. 30K, @85C (NO.)
10 mA at 12 VDC, Res. 50K, @85C (NC.) 50 A at 440 VAC, Res. 6K, @85C (NO.) |
5,9,12,24,48 VDC | 1 Form A+1 Form B
1 Form A |
1.2 W | ||
| Typical Life - Electrical | Typical Life - Mechanical | Dielectric Strength(at sea level for 1 min.) | |||
| 30k cycles @40A 440VAC Res
50k cycles @32A 440VAC Res 6k cycles @50A 440VAC Res |
100,000 operations | Contact to Coil: 4000 Vrms
Between Open Contacts: 2500 Vrms |
|||
| Terminals PC | Terminals Solder / Plug-In | Terminals Bracket Mount | Approvals | Minimum Load | Size in Inches (L x W x H) |
| Yes | No | No | UL/TUV | 5 V, 0.1 A | See data sheet |
