AZ9731 - 40 AMP MINI-ISO AUTOMOTIVE RELAY
Features:
- Quick connect terminals
- High operating temperature (125°C)
- SPST and SPDT
- Epoxy sealed versions available
- QS9000, ISO9001, ISO14001
Engineering Resources
| Contact ratings | Coil Voltage | Contact forms | Coil Power at pickup voltage | ||
|---|---|---|---|---|---|
| 40 A (NO)
30 A (NC) |
6 thru 48 VDC | 1 Form A
1 Form C |
680 mW | ||
| Typical Life - Electrical | Typical Life - Mechanical | Dielectric Strength(at sea level for 1 min.) | |||
| 100,000 operations at 40 A / 14 VDC Resistive | 10,000,000 operations | Contact to Coil: 500 Vrms
Between Open Contacts: 500 Vrms |
|||
| Terminals PC | Terminals Solder / Plug-In | Terminals Bracket Mount | Approvals | Minimum Load | Size in Inches (L x W x H) |
| No | Quick-connects | Yes | - | 5 V, 0.1 A | 1.043 x 1.043 x 0.965 |
